Rear panel components
For more information, http://www.hp.com and search for your specific thin client model to find the
model-specific QuickSpecs.
Figure 1-2 HP t610 Thin Client rear panel components
(1) DVI-I connector for DVI-D and VGA output (6) Serial connector
(2) DisplayPort connector (7) PS/2 connectors (2)
(3) Ethernet RJ-45 connector (8) Power cord retention slot
(4) Universal serial bus (USB) connectors (2) 2.0 (9) Cable lock slot
(5) Universal serial bus (USB) connectors (2) 3.0 (10) Power connector
Rear panel components 3
