Operation
3-4 HP TFT5110R User Guide
HP CONFIDENTIAL
Writer: Amy L. Laffitte File Name: d-ch3 Operation
Codename: Pug Part Number: 292491-002 Last Saved On: 10/25/02 10:18 AM
Auto Position
Auto Position automatically adjusts the position of the screen. It is a Mode setting.
Auto Phase
Auto Phase automatically adjusts the phase. It is a Global setting.
Auto Clock
Auto Clock automatically adjusts the output clock per line to match input. It is a
Global setting.
Brightness
This option displays a slider bar within the status bar to allow the adjustment of the
back light brightness.
Brightness is a Mode setting.
• Up (+) increases the current value.
• Down (-) decreases the current value.
• Select accepts the current value and exits the slider bar.
Contrast
This option displays a slider bar within the status bar to allow the adjustment of the
screen contrast. Contrast adjustments are more discernible when the background is
white. Contrast will launch Auto Level if color values are out of range.
Contrast is a Mode setting.
• Up (+) increases the current value.
• Down (-) decreases the current value.
• Select accepts the current value and exits the slider bar.
