Operation

HP TFT5110R User Guide 3-5

HP CONFIDENTIAL

Writer: Amy L. Laffitte File Name: d-ch3 Operation

Codename: Pug Part Number: 292491-002 Last Saved On: 10/25/02 10:18 AM

Image Adjust

This option contains a sub-menu:

• Horizontal Position

• Vertical Position

• Image Enhancement

• Color

• Exit

— Up (+) moves up a selection in the Image Adjust menu list.

— Down (-) moves down a selection in the Image Adjust menu list.

— Select activates one of the Image Adjust actions.

Horizontal Position

This option displays a slider bar within the status bar to allow the adjustment of the

screen’s horizontal position.

The center of the bar is obtained from the factory-preset value for Horizontal

Position. At value=MIN, the selection of + positioning response may vary between

XGA and SXGA panels. This is caused by physical limitations at MIN OSD

placement. The bar allows a range of >/= 8 and </= (Htotal - Hpixel - 9).

Horizontal Position is a Mode setting.

• Up (+) increases the current value.

• Down (-) decreases the current value.

• Select accepts the current value and exits the slider bar.
