Operation
HP TFT5110R User Guide 3-11
HP CONFIDENTIAL
Writer: Amy L. Laffitte File Name: d-ch3 Operation
Codename: Pug Part Number: 292491-002 Last Saved On: 10/25/02 10:18 AM
Advanced
This option contains a sub-menu:
• Phase Adjust
This option displays a slider bar within the status bar to allow the adjustment of
the analog signals phase.
Advanced-Phase is a Mode setting.
— Up (+) increases the current value.
— Down (-) decreases the current value.
— Select accepts the current value and exits the slider bar.
• Clock Adjust
This option displays a slider bar within the status bar to allow the adjustment of
the Horizontal Clocks.
Advanced-Clock is a Mode setting.
— Up (+) increases the current value.
— Down (-) decreases the current value.
— Select accepts the current value and exits the slider bar.
• Exit
— Up (+) moves up a selection in the Advanced menu list.
— Down (-) moves down a selection in the Advanced menu list.
— Select activates one of the Advanced actions.
