HP TouchSmart 9300 Hardware Reference Guide

Rear Components
Figure 1-4 Rear Components
Table 1-3 Rear Components
No. Component No. Component
1 Drive access panel 10 Power indicator light
2 Webcam adjustment wheel 11 Rear port security cover
3 Memory access panel 12 TV coax in (optional)
4 Adjustable reclining stand 13 IR Emitter (Blaster) output (optional)
5 Security lock slot 14 (4) USB 2.0 ports
6 Power connector release latch 15 Audio line out
7 Rear port access door 16 DisplayPort
8 USB port for optional wireless keyboard/mouse
receiver
17 RJ-45 Gigabit Ethernet port
9 Power connector
4 Chapter 1 Product Features ENWW

HP TouchSmart 9300 Specifications

General

Resolution	1920 x 1080
Audio	Integrated High Definition Audio
Storage	1TB HDD
Display	23-inch
Operating System	Windows 7
Networking	10/100/1000 Gigabit Ethernet
Wireless	802.11b/g/n
Ports	USB 2.0, Headphone, Microphone, Ethernet
