HP TouchSmart 9300 Hardware Reference Guide

5. Close the rear port access door.
Figure 2-3 Closing the Rear Port Access Door
Disconnecting Power
1. Remove all removable media, such as compact discs or USB flash drives, from the computer.
2. Turn off the computer properly through the operating system, then turn off any external devices.
3. If a security lock is installed on the rear of the computer, remove the lock.
4. If the rear port security cover is installed, remove the cover.
5. Open the rear port access door.
6. Press on the power cord release latch (1) and pull the power cord connector from the port (2).
Figure 2-4 Disconnecting Power
ENWW Disconnecting Power 11

HP TouchSmart 9300 Specifications

General

Resolution	1920 x 1080
Audio	Integrated High Definition Audio
Storage	1TB HDD
Display	23-inch
Operating System	Windows 7
Networking	10/100/1000 Gigabit Ethernet
Wireless	802.11b/g/n
Ports	USB 2.0, Headphone, Microphone, Ethernet
