HP TouchSmart 9300 Hardware Reference Guide

Connecting Power
1. Squeeze the two tabs on the rear port access door at the back of the computer (1) and pull the
door open (2).
Figure 2-1 Opening the Rear Port Access Door
2. Reach into the rear cavity framed by the computer stand and plug the power cord into the power
connection at the top right corner (1).
3. Plug the three-pronged power plug into the power brick (2) and a power outlet (3).
Figure 2-2 Connecting Power
4. Plug all peripheral cables into the appropriate ports as needed.
10 Chapter 2 Hardware Upgrades ENWW

HP TouchSmart 9300 Specifications

General

Resolution	1920 x 1080
Audio	Integrated High Definition Audio
Storage	1TB HDD
Display	23-inch
Operating System	Windows 7
Networking	10/100/1000 Gigabit Ethernet
Wireless	802.11b/g/n
Ports	USB 2.0, Headphone, Microphone, Ethernet
