HP V1910 Series User Manual

6
HP V1910-24G-PoE (365W) Switch JE007A
Front panel
Figure 9 HP V1910-24G-PoE (365W) Switch JE007A front panel
(1) 10/100/1000Base-T auto-sensing Ethernet port (2) Port status LED mode switching button
(3) RPS status LED (RPS) (4) Port status LED
(5) Power LED (Power) (6) Port mode LED
(7) Console port (8) Port 1000Base-X SFP interface
Rear panel
Figure 10 HP V1910-24G-PoE (365W) Switch JE007A rear panel
1 2 3 4
(1) DC power receptacle (2) Screw hole of the plu
g
(3)
A
C receptacle (4) Groundin
g
screw
Power supply system
The HP V1910-24G-PoE (365W) Switch JE007A can adopt AC power input, or DC power input, or both
to provide backup
 AC power input:
Rated voltage range: 100 VAC to 240 VAC, 50 Hz or 60 Hz
Input voltage range: 90 VAC to 264 VAC, 47 Hz or 63 Hz
 DC power input
Rated voltage range: –52 VDC to –55 VDC
CAUTION:
Only the RPS recommended by HP can be used for the HP V1910-24G-PoE (365W) Switch JE007A. The
–48 VDC power supply in the equipment room cannot be used directly. Otherwise, the switch may be
damaged.

HP V1910 Series Specifications

General

Model	HP V1910 Series
Ports	8, 24, or 48
Uplink Ports	Varies by model
Switching Capacity	Varies by model (Up to 104 Gbps)
Forwarding Rate	Varies by model (Up to 77.3 Mpps)
Layer	Layer 2
Management	Web-managed
VLAN Support	Yes
QoS	Yes
MAC Address Table Size	8, 192 entries
Jumbo Frame Support	Yes
Power Supply	Internal
Power Consumption	Varies by model
Dimensions	Varies by model
Weight	Varies by model
Operating Temperature	32°F to 113°F (0°C to 45°C)
Operating Humidity	10% to 90% (non-condensing)
