HDMI connector J3
Repair the HDMI connector:
1) Use a soldering iron and a de-soldering pump to remove as much solder as possible from the pin.
2) Use a hot air gun to melt the solder on the pins.
3) Lift the J3 connector from the circuit board.
4) Place the new component on the circuit board. Be sure that it matches the footprint.
5) Solder the new component.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP V22v G5 and is the answer not in the manual?

HP V22v G5 Specifications

General IconGeneral
Display Size21.5 inches
Panel TypeVA
Refresh Rate75 Hz
Aspect Ratio16:9
Brightness250 nits
VESA Mount100 x 100 mm
Resolution1920 x 1080
Response Time5 ms
Ports1 x VGA; 1 x HDMI 1.4
Viewing Angle178° horizontal / 178° vertical
Contrast Ratio3000:1
