Physical Characteristics
For more information, refer to the PC’s data sheet in the library on HP’s web site www.hp.com/desktop.
Power Consumption
NOTE When the PC is turned off with the power button on the front panel, the power consumption falls
below 5 Watts, but is not zero. The special on/off method used by this PC considerably extends
the lifetime of the power supply and battery. To reach zero power consumption in “off” mode,
either unplug the PC from the power outlet or use a power block with a switch.
Acoustic Noise Emission
Characteristic Desktop PC Minitower PC
Weight (excl. display and
keyboard)
10.4 kg (22.9 pounds) 14.8 kg (32.6 pounds)
Dimensions Width: 44.3 cm (17.4 inches),
Height: 13.8 cm (5.4 inches),
Depth: 43.5 cm (17.1 inches)
Width: 20.7 cm (8.1 inches),
Height: 46.9 cm (18.5 inches),
Depth: 45.5 cm (17.9 inches)
Footprint 0.193 m
2
(2.07 ft
2
) 0.094 m
2
(1.01 ft
2
)
Storage temperature –40 ºC to 70ºC (–40 ºF to 158 ºF) –40 ºC to 70ºC (–40 ºF to 158 ºF)
Storage humidity 8% to 85% (relative), non-condensing at 40ºC (104 ºF) 8% to 85% (relative), non-condensing at 40ºC (104 ºF)
Operating temperature 10 ºC to 35 ºC (50 ºF to 95 ºF) 10 ºC to 35 ºC (50 ºF to 95 ºF)
Operating humidity 15% to 80% (relative) 15% to 80% (relative)
Power supply Input voltage: 100 – 127 V 6.0A, 200 – 240V 3.0A ac
(voltage selection switch)
Input frequency: 50/60 Hz
Maximum output power: 200W continuous
Input voltage: 100 – 127 V 6.0A, 200 – 240V 3.0A ac
(voltage selection switch)
Input frequency: 50/60 Hz
Maximum output power: 200W continuous
Power Consumption
(Windows NT 4.0 and Windows 95)
Desktop Models Minitower Models
115V / 60Hz 230V / 50Hz 115V / 60Hz 230V / 50Hz
Operating without I/O ≤ 37.0 W ≤ 37.0 W ≤ 41.0 W ≤ 41.0 W
Standby ≤ 29.0 W ≤ 29.0 W ≤ 29.0 W ≤ 29.0 W
Off ≤ 4.0 W ≤ 4.0 W ≤ 4.0 W ≤ 4.0 W
Acoustic Noise Emission
1
(Measured according to ISO 7779)
Desktop Models Minitower Models
Sound Power
(typical)
Sound Pressure
(typical)
Sound Power
(typical)
Sound Pressure
(typical)
Operating LwA ≤ 37 dB LpA ≤ 30 dB LwA ≤ 36 dB LpA ≤ 30 dB
Operating with HDD access LwA ≤ 38 dB LpA ≤ 31 dB LwA ≤ 37 dB LpA ≤ 31 dB
Operating with FDD access LwA ≤ 42 dB LpA ≤ 39 dB LwA ≤ 42 dB LpA ≤ 38 dB
1. Typical measures with 5400 rpm hard disk drive.
