Page #11 background imageLoading...
Page #11 background image
8
How to order parts
The HP authorized repair center can purchase the power board from HP.
Power board
Description
HP spare part number
Manufacturer part
number
PSU HP X27qc
M84745-001
M84745-002
PLPCKH362UQA1
PLPCLH421UQA5
Capacitors and connectors are available for purchase from the following EU distributors:
RS: Capacitors | RS Components (rs-online.com)
Digi-Key: Digikey Electronics
Capacitors by distributor
Component description
Location
Component
distributor
Distributor part number
EC 680uF 20% 35V
12.5*20 3000 hr 2A
PY1V
C905/C906
digikey
EGPA350ELL681MK20S
EC 470uF 20% 25V
10x12 5000 hr 1.6A
ENB1
C9905
RS
EEUFR1E471
Connectors by manufacturer
Component description
Location
identifier
Component
distributor
Distributer part
number
HDMI
CN5101
RS
SD-47151-001
(Molex)
DP
CN551
digikey
DP1RD20JQ3
(JAE)
AUDIO
CN601
RS
913-1021
(RS PRO)
NOTE: Rear cover and chassis need to be modified to hold connector. Connector may need
modifications to meet functional, safety and regulatory requirements accordingly if it doesn’t match
exactly.
You can purchase cables from the HP part store at https://partsurfer.hp.com/Search.aspx.
Internal and External Power Supplies are available for purchase from the following EU distributor: EET
https://www.eetgroup.com/en-eu/
NOTE: HP continually improves and changes product parts. For complete and current information
about supported parts for your product, go to https://partsurfer.hp.com/Search.aspx, select your
country or region, and then follow the on-screen instructions.
