HP Z230 User Manual

Activity Possible cause Recommended action
Red Power LED blinks
four times, once every
second, followed by a
two-second pause. Four
beeps.
Power failure (power
supply is overloaded).
CAUTION: Internal components might be powered even when
the computer is off. To prevent damage, disconnect the
computer power cord before you remove a component.
1. Open the access panel and make sure that all power
connections are secure on the system board.
2. Check if a device is causing the problem by removing all
attached devices (such as hard, diskette, or optical disk
drives, and expansion cards.) Turn on the computer. If the
system enters the POST, power off and replace one device
at a time; repeat this procedure until failure occurs. Replace
the device that is causing the failure. Continue adding
devices one at a time to make sure that all devices are
functioning properly.
Red Power LED blinks
five times, once every
second, followed by a
two-second pause. Five
beeps.
Pre-video memory error. CAUTION: Internal components might be powered even when
the computer is off. To prevent damage, disconnect the
computer power cord before you remove a component.
1. Reseat DIMMs.
2. Replace DIMMs one at a time to isolate faulty module.
3. Replace third-party memory with HP memory.
4. The problem might be on the system board. Contact HP for
assistance.
Red Power LED blinks six
times, once every second,
followed by a two-second
pause. Six beeps.
Pre-video graphics
error.
CAUTION: Internal components might be powered even when
the computer is off. To prevent damage, disconnect the
computer power cord before you remove a component.
1. Reseat the graphics card.
2. Verify the graphics auxiliary power cable is connected (if
applicable).
3. Confirm the graphics card is in the appropriate slot (PCIe
x16).
4. The problem might be on the graphics card. Contact HP for
assistance.
Red Power LED blinks
seven times, once every
second, followed by a
two-second pause. Seven
beeps.
System board failure
(ROM detected failure
prior to video).
1. Clear CMOS.
NOTE: Refer to the
Maintenance and Service Guide for
the computer model for detailed information on clearing
CMOS.
2. The problem might be on the system board. Contact HP for
assistance.
Red Power LED blinks
eight times, once every
second, followed by a
two-second pause. Eight
beeps.
Invalid ROM based on
bad checksum.
CAUTION: Internal components might be powered even when
the computer is off. To prevent damage, disconnect the
computer power cord before you remove a component.
1. Clear CMOS.
NOTE: Refer to the
Maintenance and Service Guide for
the computer model for detailed information on clearing
CMOS.
2. Upgrade the ROM using SoftPaq, either from the hard
drive, CD, diskette, or USB removable device (for example,
HP Drive Key). See the ROM Flash section of the
Maintenance and Service Guide at http://www.hp.com/
support/workstation_manuals. SoftPaq is a self-extracting
Diagnostic codes and errors 93

HP Z230 Specifications

General

Product type	Workstation
Motherboard chipset	Intel® C226
ECC	Yes
Memory slots	4x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	1 x 4 GB
Chassis type	Desktop
Product color	Black
Country of origin	China
Placement supported	Vertical
Number of 3.5\" bays	1
Water cooling system	No
HDD speed	7200 RPM
RAID levels	0, 1
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Total storage capacity	500 GB
PS/2 ports quantity	2
DisplayPorts quantity	3
Serial ports quantity	-
USB 2.0 ports quantity	6
VGA (D-Sub) ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Ethernet LAN data rates	10, 100, 1000 Mbit/s
On-board graphics card ID	0x412
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4600
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	11.1
On-board graphics card dynamic frequency (max)	1150 MHz
Power supply	240 W
Tcase	72.72 °C
Bus type	DMI2
Stepping	C0
Processor cache	6 MB
Processor model	i5-4570
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor socket	LGA 1150 (Socket H3)
Processor codename	Haswell
Processor frequency	3.2 GHz
Processor cache type	Smart Cache
Processor lithography	28 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.6 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	84 W
Maximum number of PCI Express lanes	16
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Operating system installed	Windows 7 Professional
Scalability	1S
Processor code	SR14E
Processor ARK ID	75043
Intel TSX-NI version	0.00
Processor package size	37.5 x 37.5 mm
Graphics & IMC lithography	22 nm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal solution specification	PCG 2013D
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	384 mm
Width	337 mm
Height	100 mm
Weight	7200 g
