HP Z230 User Manual

Device Options Allows you to set:
●
Turbo Mode—(Enable/Disable). Allows you to enable and disable the Intel Turbo Mode
feature, which allows one core of the system to run at a higher than standard frequency and
power if other cores are idle. Default is enabled.
●
S5 Wake on LAN—(Enable or Disable)
●
Num Lock State at Power-On—(On or Off). Default is off.
●
IGD Memory—(32, 64, 128, 256, 512) Controls how much system RAM is reserved for use
by the internal graphics device. The value you choose is allocated permanently to graphics
and is unavailable to the operating system. For example, if you set this value to 512M on a
system with 2 GB of RAM, the system always allocates 512 MB for graphics and the other
1.5 GB for use by the BIOS and operating system.
●
Integrated Video (Enable/Disable). Use this option to disable the integrated video controller
when another video controller is present in the system. Default is enabled.
●
Internal Speaker (does not affect external speakers)—(Enable/Disable). Default is enabled.
●
USB EHCI Port Debug—(Enable/Disable)
●
Multi-Processor—(Enable/Disable). Use this option to disable multi-processor support under
the OS. Default is enabled.
●
Hyper threading—(Enable/Disable). Use this option to disable processor hyper-threading.
Slot Settings Lets you Enable/Disable Option ROM Download for each slot. Selective disabling of Option ROM
downloads can help manage limited Option ROM space. Limit PCIe Frequency to Gen1, Gen2,
Gen3. Runs slot at Gen1, Gen2, or Gen3 frequency.
VGA Configuration Displayed only if there is an add-in video card in the system. Allows you to specify which VGA
controller will be the “boot” or primary VGA controller.
Management
Operations
Allows you to set:
●
AMT—(Enable/Disable). Allows you to enable or disable functions of the embedded
Management Engine (ME) such as Active Management Technology (AMT). If set to disable,
the Management Engine is set to a temporarily disabled state and will not provide functions
beyond necessary system configuration. Default is enabled.
●
Unconfigure AMT/ME—(Enable/Disable). Allows you to unconfigure any provisioned
management settings for AMT. The AMT settings are restored to factory defaults. This
feature should be used with caution as AMT will not be able to provide any set AMT
management functions once unconfigured. Default is disabled.
●
Hide Unconfigure ME Confirmation Prompt—(Enable/Disable). Allows you to set the system
to not display the confirmation to unconfigure ME.
●
Watchdog Timer—(Enable/Disable). Allows you to set amount of time for an operating
system and BIOS watchdog alert to be sent if the timers are not deactivated. BIOS watchdog
is deactivated by BIOS and would indicate that a halt occurred during execution if the alert is
sent to the management console. An operating system alert is deactivated by the operating
system image and would indicate that a hang occurred during its initialization. Default is
enabled.
Option ROM Launch
Policy
●
PXE Option ROMs—(Legacy, UEFI Only/Do Not Launch)
●
StorageOption ROMs—(Legacy, UEFI Only/Do Not Launch)
●
Video Options—(Legacy, UEFI Only)
Connected BIOS
●
Connected BIOS—(Enable/Disable)
●
Use Proxy—(Enable/Disable)
Update BIOS via
Network
●
Update BIOS via Network—(Enable/Disable)
●
Update Source
34 Chapter 2 System management

HP Z230 Specifications

General

Product type	Workstation
Motherboard chipset	Intel® C226
ECC	Yes
Memory slots	4x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	1 x 4 GB
Chassis type	Desktop
Product color	Black
Country of origin	China
Placement supported	Vertical
Number of 3.5\" bays	1
Water cooling system	No
HDD speed	7200 RPM
RAID levels	0, 1
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Total storage capacity	500 GB
PS/2 ports quantity	2
DisplayPorts quantity	3
Serial ports quantity	-
USB 2.0 ports quantity	6
VGA (D-Sub) ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Ethernet LAN data rates	10, 100, 1000 Mbit/s
On-board graphics card ID	0x412
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4600
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	11.1
On-board graphics card dynamic frequency (max)	1150 MHz
Power supply	240 W
Tcase	72.72 °C
Bus type	DMI2
Stepping	C0
Processor cache	6 MB
Processor model	i5-4570
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor socket	LGA 1150 (Socket H3)
Processor codename	Haswell
Processor frequency	3.2 GHz
Processor cache type	Smart Cache
Processor lithography	28 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.6 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	84 W
Maximum number of PCI Express lanes	16
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Operating system installed	Windows 7 Professional
Scalability	1S
Processor code	SR14E
Processor ARK ID	75043
Intel TSX-NI version	0.00
Processor package size	37.5 x 37.5 mm
Graphics & IMC lithography	22 nm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal solution specification	PCG 2013D
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	384 mm
Width	337 mm
Height	100 mm
Weight	7200 g
