HP Z230 User Manual

Problem Cause Solution
Drive not found (identified) Improper cable connection On computers with discrete data and power cables, make
sure that the data and power cables are securely
connected to the hard drive. (See the
Hard drive section
of this guide for connection details.)
Improperly seated hard drive On systems with blind-mate drive connections, check for
connector damage on the drive and in the chassis.
Reseat the hard drive and its carrier in the chassis to
make sure that a proper connection. (See the
Hard drive
section of this guide for connection details.)
The system might not have
automatically recognized a
newly installed device.
1. Run Computer Setup (f10) Utility.
2. If the system does not recognize the new device,
verify that the device is listed in Computer Setup
(f10) Utility.
If it is listed, the probable cause is a driver problem.
If it is not listed, the probable cause is a hardware
problem.
3. If this drive is newly installed, enter Setup and try
adding a POST delay under Advanced > Power-On.
Drive responds slowly
immediately after power-up.
Run Computer Setup (f10) Utility and increase the POST
Delay in Advanced.> Power-On Options
Non-system disk or NTLDR
missing message
System is trying to start from
nonbootable media.
Remove the optical disc or USB drive.
System is trying to start from
a damaged hard drive.
1. Insert a bootable system optical disc or USB drive
and restart the computer.
2. If the hard drive is still inaccessible and MBR
Security is enabled, try restoring the previously
saved MBR image by entering Setup and selecting
Security > Restore Master Boot Record.
System files missing or not
properly installed.
1. Insert a bootable system optical disc or USB drive
and restart.
2. Verify that the hard drive is partitioned and
formatted.
3. Install the system files for the appropriate operating
system, if necessary.
Hard drive boot disabled in
Computer Setup.
Run Computer Setup (f10) Utility and enable the hard
drive entry in the Storage > Boot Order list.
Workstation will not start. Hard drive is damaged. Replace the hard drive.
84 Chapter 4 Diagnostics and troubleshooting

HP Z230 Specifications

General

Product type	Workstation
Motherboard chipset	Intel® C226
ECC	Yes
Memory slots	4x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	32 GB
Memory layout (slots x size)	1 x 4 GB
Chassis type	Desktop
Product color	Black
Country of origin	China
Placement supported	Vertical
Number of 3.5\" bays	1
Water cooling system	No
HDD speed	7200 RPM
RAID levels	0, 1
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Total storage capacity	500 GB
PS/2 ports quantity	2
DisplayPorts quantity	3
Serial ports quantity	-
USB 2.0 ports quantity	6
VGA (D-Sub) ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Ethernet LAN data rates	10, 100, 1000 Mbit/s
On-board graphics card ID	0x412
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4600
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	11.1
On-board graphics card dynamic frequency (max)	1150 MHz
Power supply	240 W
Tcase	72.72 °C
Bus type	DMI2
Stepping	C0
Processor cache	6 MB
Processor model	i5-4570
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor socket	LGA 1150 (Socket H3)
Processor codename	Haswell
Processor frequency	3.2 GHz
Processor cache type	Smart Cache
Processor lithography	28 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.6 GHz
Processor operating modes	64-bit
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	84 W
Maximum number of PCI Express lanes	16
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Operating system installed	Windows 7 Professional
Scalability	1S
Processor code	SR14E
Processor ARK ID	75043
Intel TSX-NI version	0.00
Processor package size	37.5 x 37.5 mm
Graphics & IMC lithography	22 nm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal solution specification	PCG 2013D
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	384 mm
Width	337 mm
Height	100 mm
Weight	7200 g
