HP ZBook 17 User Manual

13 Backup and Recovery in SUSE Linux
Recovery after a system failure is as good as your most recent backup. As you add new software and
data files, you should continue to back up your system on a regular basis to maintain a reasonably
current backup.
Your computer includes tools provided by HP to help you safeguard your information and retrieve it if
ever needed.
Creating backups
1. Create restore media immediately after you set up the computer.
2. As you add files, routinely create a backup of your system and personal information.
Creating restore media
You can create an HP Factory Image, using an installed or an external DVD±RW optical drive or a USB
drive. The HP Factory Image can be used to perform system recovery in the event of a system failure.
The recovery tool reinstalls the original operating system and HP programs and drivers that were
installed at the factory.
To create the restore media:
1. Select Computer > More Applications.
2. In the left pane, click Tools, and then click Create HP Factory Image in the right pane.
3. Follow the on-screen instructions to create an image file to burn a recovery disc.
NOTE: The image produced by HP Create Factory Image can be written to a USB disk on key
or a DVD. If you are writing to a DVD, follow the on-screen instructions. To write the image to a
USB disk on key:
To write the image to a USB disk on key:
a. Insert the USB disk on key in a USB port.
b. To transfer the image to a USB disk on key, use the dd command.
150 Chapter 13 Backup and Recovery in SUSE Linux

HP ZBook 17 Specifications

General

Bus type	DMI2
Stepping	C0
Tjunction	100 °C
Processor cache	6 MB
Processor cores	4
System bus rate	- GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-4700 Mobile series
Processor socket	PGA946
Processor threads	8
Processor codename	Haswell
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.4 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	47 W
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	32 GB
Audio system	DTS Studio Sound HD
Product type	Mobile workstation
Motherboard chipset	Intel® QM87
Password protection	Yes
Memory slots	4x SO-DIMM
Internal memory	8 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Memory form factor	SO-DIMM
Memory layout (slots x size)	2 x 4 GB
Form factor	Clamshell
Pointing device	Touchpad
Battery life (max)	- h
Disc types supported	CD, DVD
Headphone connectivity	3.5 mm
eSATA/USB 2.0 ports quantity	0
HDD capacity	0 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	SATA
Storage media	SSD
Optical drive type	DVD-ROM
Total storage capacity	256 GB
Compatible memory cards	SD, SDHC, SDXC
Number of SSDs installed	1
Display surface	Matt
Display diagonal	17.3 \
Native aspect ratio	16:9
Display number of colors	16.78 million colors
On-board graphics card ID	0x416
Discrete graphics card model	NVIDIA® Quadro® K3100M
On-board graphics card model	Intel® HD Graphics 4600
Discrete graphics card memory	4 GB
Discrete graphics memory type	GDDR5
On-board graphics card family	Intel® HD Graphics
On-board graphics card memory	1.7 GB
Maximum on-board graphics card memory	1.74 GB
On-board graphics card base frequency	400 MHz
On-board graphics card DirectX version	11.1
On-board graphics card dynamic frequency (max)	1150 MHz
Number of displays supported (on-board graphics)	3
Number of built-in speakers	2
Front camera resolution	1280 x 720 pixels
WWAN	Not installed
Data network	Not supported
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Microphone in	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Recovery operating system	Windows 8 Pro
Operating system installed	Windows 7 Professional
Product color	Black
Country of origin	China
Processor code	SR15H
Processor ARK ID	75117
Intel TSX-NI version	0.00
Processor package size	37.5 x 32 x 1.6 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Intel Identity Protection Technology version	1.00
Battery capacity	75 Wh
AC adapter power	200 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	5.27 A
AC adapter output voltage	19 V
Operating altitude	0 - 3050 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	RoHS, EPEAT Silver, ENERGY STAR

Weight and Dimensions

Depth	272 mm
Width	416 mm
Height	34 mm
Weight	3480 g
