Keyboard
NOTE: For a detailed list of available keyboards, see Sequential part number listing on page 36.
Description Spare part number
Keyboard 733688-xx1
Before removing the keyboard, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 46).
5. Remove the service door (see
Service door on page 48).
6. Remove the optical drive (see
Optical drive on page 57) or upgrade bay hard drive (see Upgrade
bay hard drive on page 59).
NOTE: The optical drive or hard drive carrier in the upgrade bay must be removed to remove the
keyboard.
Remove the keyboard:
1. Position the computer upside down.
Component replacement procedures
63
