Webcam module
Description Spare part number
Webcam module with microphone 734295-001
Microphone module 735370-001
Before removing the webcam module, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 46).
5. Remove the display bezel (see
Display bezel on page 67).
Remove the webcam module:
1. Disconnect the cable from the webcam (1).
2. Pry to remove the webcam module from the display enclosure (2). The webcam module is secured
with adhesive.
Reverse this procedure to install the webcam module.
Component replacement procedures
69
