3. Lift the tape that covers the connector on the back of display panel (1), and then disconnect the
display panel cable (2).
4. Remove the eight Phillips PM2.0×3.0 screws (1) that secure the panel to the hinges.
5. Slide the display panel up and out of the hinges (2).
To replace the remaining display components, you must remove the display from the computer.
Reverse this procedure to install the display panel. For more information, see
Display assembly
on page 84.
Component replacement procedures
71
