14 User Manual
1.2 Speed and Switching
Table 3 describes maximum throughput and interface speed per system model.
*The system can support different interfaces and speed rates using QSFP to SFP adapters or
hybrid cables. For further information, see
“Breakout Cables and Adapters”.
1.3 Management Interfaces, PSUs and Fans
Table 4 lists the various management interfaces, PSUs and fans per system model.
1.4 Features
For a full feature list, please refer to the system’s product brief in HPE’s website: https://
www.hpe.com.
1.5 Certifications
The list of certifications (such as EMC, Safety and others) per system for different regions of the
world is located on the HPE website at:
Table 3 - Speed and Switching Capabilities
System Model 10/25GbE SFP28 Interfaces*
40/50/56/100GbE
QSFP28 Interfaces*
Max Throughput
SN2700M 64 (using QSFP to SFP breakout
cables)
32 3.2Tb/s
SN2410M/
SN2410bM
Total 64, 48zSFP+ 16 (using
QSFP to SFP breakout cables)
8 2Tb/s
SN2100M 64 (using QSFP to SFP breakout
cables)
16 (or 32 50GbE
interfaces when
using QSFP to
2xQSFP breakout
cables).
1.6Tb/s
SN2010M 34 (using QSFP to SFP splitter
cables)
4 (or 8 50GbE
interfaces when
using QSFP to
2xQSFP splitter
cables).
1.7 Tb/s
Table 4 - Management Interfaces, PSUs and Fans
System Model USB MGT Console PSU Fan
SN2700M Rear Rear (2 ports) Rear 2 units 4 units
SN2410M/
SN2410bM
Rear Rear (2 ports) Rear 2 units 4 units
SN2100M Front (mini
USB)
Front (1 port) Front 2 units (non-
replaceable)
4 units (non-
replaceable)
SN2010M Front Front (1 port) Front 2 units (non-
replaceable)
4 units (non-
replaceable)
