Frame link module spare partFrame link module spare part

Customer self repair: mandatorymandatory

DescriptionDescription Spare part numberSpare part number

HPE Synergy Frame Link Module (2-port) 807963-001

HPE Synergy 4-Port Frame Link Module P04749-001

Frame link module spare part 23
