Chapter 3 Mechanical Installation Shenzhen Hpmont Technology Co., Ltd
―14― HD30 Series Inverters User Manual
Table 3-2 HD30 dimensions
Model HD30- W W1 H H1 H2 D d Figure
Gross
weight
2D0P4G
135 91 241 226 220 162 5 1 2
2D0P7G
2D1P5G
2D2P2G
4T0P7G
4T1P5G
4T2P2G
2T3P7G
165 115 266 253 245 190 5 1 3.2
4T3P7G/5P5P
4T5P5G/7P5P
2T5P5G
200 146 299 286 280 210 5 1 5
4T7P5G/011P
4T011G/015P
2T7P5G
235 167 353 337 330 222 7 1 8.5
4T015G/018P
4T018G/022P
2T011G
290 235 469 445 430 240 8 2 18
2T015G
2T018G
4T022G/030P
4T030G/037P
2T022G
380 260 598 576 550 290 10 2 37
2T030G
2T037G
4T037G/045P
4T045G/055P
4T055G/075P
In the Table 3-2, the mm and the Kg are respectively units of the size and the gross weight.
