4.7 Setting DIP switch
4.7.1 Serial interface（RS-232C）
·DIP switch 1
Switches
Functions
Turn on
Turn off
Default
1-1
Line feed automatic
Yes
Prohibit
Turn off
1-2
Handshaking
XON/XOFF
DTR/DSR
Turn off
1-3
Data length
7 bit
8 bit
Turn off
1-4
Odd-even verify
Yes
No
Turn off
1-5
Odd-even choice
EVEN
ODD
Turn off
1-6
Choice baud rate（bps）
Reference form 1
Turn off
1-7
Turn on
1-8
Turn off
DIP switch 2
Switches
Functions
Turn on
Turn off
Default
2-1
The mode switch in both
Chinese and English
English
Chinese
Turn on
2-2
Internal control beeper
Permit
Prohibit
Turn off
2-3
Auto cutter
Prohibit
Permit
Turn off
2-4
Busy condition
Receive buffer is full
*Off-line
* Receive buffer is full
Turn off
2-5
Printer density
Reference form 2
Turn off
2-6
Turn off
2-7
Turn off
2-8
Paper out sensor status
Prohibit
Permit
Turn off
4.7.2 Interfaces of Parallel and USB2.0
DIP switch 1
Switches
Function
Turn on
Turn off
Default
1-1
Line feed automatic
Permit
Prohibit
Turn off
1-2～1-8
Reserve
-
-
Turn off
DIP switch 2
Switches
Functions
Turn on
Turn off
Default
2-1
The mode switch in both
Chinese and English
English
Chinese
Turn on
2-2
Internal control beeper
Prohibit
Permit
Turn off
2-3
Auto cutter
Prohibit
Permit
Turn off
2-4
Busy condition
Receive buffer is full
*Off-line
* Receive buffer is full
Turn off
2-5
Printer density
Reference form 2
Turn off
2-6
Turn off
2-7
Turn off
2-8
Paper out sensor status
Prohibit
Permit
Turn off
