5 Interfaces signal
Printer TP801/TP805/TP806 supports cash drawer interface and many other various
communicate interfaces, such as Serial interface, parallel interface, USB interface,
Ethernet interface (TP801/TP806 also support Wi-Fi interface). The printer has the
communication board with the default USB interface and cash drawer interface, and
the other communication boards with the Ethernet interface, parallel interface,
RS232 interface are optional.
5.1 Parallel interface
Parallel interface (TP801/TP805/TP806 support TM-T88IV protocol) supports protocol
with 36 pin CENTRONICS socket.
Pin No.
Signal
Source
Signal Definition
1
H
Data latch pulse, latch the data to the printer at the rising edge of the negative pulse
2
H
Data 0(The lowest bit)
3
H
Data 1
4
H
Data
2Si
5
H
Data
3
6
H
Data
4
7
H
Data
5
8
H
Data
6
9
H
Data
7 (
The highest bit
)
10
P
Printer response signal, indicates that the printer has received the last byte of data; A
negative pulse of about 1us.
11
P
Busy Signal; The printer is busy; High level indicates that the printer can’t receive data.
12
P
PE Signal; paper end signal; High level indicates that the printer is paper end.
13
－
Unconnected
14
－
Unconnected
15
－
Unconnected
16
Logic Ground
17
Frame Ground, separated from logic ground
18
－
Unconnected
19~30
Logic Ground
31
－
Unconnected
32
P
Printer error signal, low level indicates that error occurs in the printer, the error signal will
output along with paper end signal.
33
Logic Ground
34~35
－
Unconnected
36
－
Unconnected
