Pos. Description Part No. Remarks
1 CHASSIS HTC 650/800 HANDLE 110057
2 CONSOLE CONTROL PANEL 110058
3 SCREW RXS B10X16 GALV 310029
4 SCREW MC6S M6X12 8.8 GALV 310030
5 WASHER BRB M6 GALV 310012
6 WIRING HOLDER (CLIP) JR12 110059
7 WASHER BRB M6 GALV 310012
8 SCREW MC6S M6X12 8.8 GALV 310030
9 WIRING HOLDER (CLIP) JR12 110059
10 WASHER BRB M6 GALV 310012
11 SCREW MC6S M6X12 8.8 GALV 310030
12 CHASSIS HTC 650/800 POST 110060
13 SCREW M6S M16X120 GALV 310031
14 WASHER BRB M16 GALV 310032
15 SPRINT CHASSIS HTC 650/800 110061
16 WASHER BRB M16 GALV 310032
17 NUT NYLOCK M16 GALV DIN985 310033
18 SCREW MF6S M8X25 GALV 310071
19 TANK BRACKET 110062
20 WASHER BRB M6 GALV 310012
21 SCREW MC6S M6X12 8.8 GALV 310030
22 FREQUENCY CONVERTER 7.5 kw According to
specification
22 SOFT START 5.5 kw According to
specification
22a PROTECTIVE CAGE FREQUENCY CONVERTER 110158
22a PROTECTIVE CAGE SOFT START 110003
23 SCREW M6S M12X65 GALV 310034
24 NUT NYLOCK M12 GALV DIN985 310004
25 CHASSIS HTC 650 BOTTOM 110643
26 WHEEL FITTING KIT 110008
27 WHEEL HTC 650 WKCP 2803 6553 110350
28 WATER VALVE TO GRINDER 110007
29 SCREW M6S M5X20 GALV 310010
30 WATER TANK HTC 650/800 110069
31 MOTOR 7.5 DPIG 132M-4 200/346 110226
31 MOTOR 5.5KW DPIG132S-4,400/690 110368
31 MOTOR 5.5KW DPIG132S-4 200/400 110312
32 SCREW M6S M12X25 GALV 310011
33 WASHER BRB M12 GALV 310003
34 SCREW MC6S M6X25 12.9 GALV 310035
35 WASHER BRB M6 GALV 310012
36 COVER HTC 650 COMPLETE 110121
37 FIXING LUG 110072
Parts list, HTC 650
