HTC 500 - Parts List - HTC 800 E

25
Parts list - HTC 800 E
Pos. Description Part No. Remarks
1 CHASSIS HTC 650/800 HANDLE 110057
1A SHRINK TUBING TO HTC HANDLE 110308
2 COVER PLUG TO HTC HANDLE 110357
3 CONSOLE CONTROL PANEL 110058
4 SCREW RXS B10X16 GALV 310029
5 CONTROL PANEL, COMPLETE 110122
5A EMERGENCY STOP, COMPLETE XB4 110481
5B POTENTIOMETER COMPLETE 110500
5C ON/OFF KNOB, COMPLETE 110499
5D LAMP, GREEN 110491
5E RESET BUTTON COMPLETE 110498
5F FRONT/BACK KNOB, COMPLETE 110485
6 SCREW MC6S M6X12 8.8 GALV 310030
7 WASHER BRB M6 GALV 310012
8 SCREW MC6S M6X12 8.8 GALV 310030
9 WASHER BRB M6 GALV 310012
10 WIRING HOLDER (CLIP) JR12 110059
11 SCREW MC6S M6X12 8.8 GALV 310030
12 WASHER BRB M6 GALV 310012
13 WIRING HOLDER (CLIP) JR12 110059
14 CHASSIS HTC 650/800 POST 110060
15 SCREW M6S M16X120 GALV 310031
16 WASHER BRB M16 GALV 310032
17 NUT NYLOCK M16 GALV DIN985 310033
18 WASHER BRB M16 GALV 310032
19 SPRINT CHASSIS HTC 650/800 110061
20 HAIR PIN, GALV 3.5X75 310125
21 SCREW MC6S M6X12 8.8 GALV 310030
22 WASHER BRB M6 GALV 310012
23 TANK BRACKET 110062
24 FREQUENCY CONVERTER 7.5 kW as specified
24A RUNNING TIME METRE CURTIS 110309
25 CHASSIS HTC 650/800 PROTECTIVE CAGE 110158
26 SCREW MF6S M8X25 GALV 310071
27 WALL SOCKET 16A 200-250V 3P BLUE 110534
28 SCREW M6S M5X20 GALV 310010
29 WALL INLET 16A 346-415V 5P RED as specified
30 PHASE INDICATOR 4 DIODES 16A 400 VOLTS 110229
PHASE INDICATOR 3 DIODES 200V 110344
31 SCREW M6S M5X20 GALV 310010
32 WASHER BRB M5 GALV 310194
33 NUT M6M M5 GALV 310193
34 CONNECTOR, FEMALE, MOTOR as specified
