26
Pos. Description Part No. Remarks
35 SCREW not available
36 CONNECTOR, MALE, MOTOR as specified
37 ELECTRICAL CABLE, MOTOR as specified
38 CONTROL PANEL CABLE as specified
39 CONTROL PANEL CABLE as specified
40 WATER TANK HTC 650/800 110069
41 NUT 1253-3/8 (T-HOSE CONNECTOR) 110332
42 HOSE CONNECTOR 2601-12-3/8 110147
43 HOSE CONNECTOR 2601-12-1/4 110205
44 ELBOW-PIPE-IU 2020-1/4 110146
45 WATER VALVE TO GRINDER 110007
46 HOSE LARGE REINFORCED PVC 110130
47 SCREW M6S M5X20 GALV 310010
48 CHASSIS HTC 800 BOTTOM 110619
49 SCREW M6S M12X65 GALV 310034
50 WASHER BRB M12 GALV 310003
51 NUT NYLOCK M12 GALV DIN985 310004
52 WHEEL HTC 800 110382
53 CAP, WHEEL not available
54 CIRCLIP SGA 20 310016
55 BALL BEARING HTC800 WHEEL, OUTER 110279
56 BALL BEARING HTC800 WHEEL, INNER 110278
57 GASKET, WHEEL not available
58 MOTOR 7.5 DPIG 132M-4 200/346 110226
59 SCREW M6S M12X25 GALV 310011
60 WASHER BRB M12 GALV 310003
61 COVER HTC 800 NEW MODEL, HIGH 110133
62 T-PIPE 10MM 110144
63 HOSE, POLYURETHANE TUBE 10/7 BLACK 110145
64 WIRING HOLDER (CLIP) JR14 110359
65 POP RIVET 4.8X12.7 310084
66 PIPE, PEH 50 LK 110383
67 VELCRO MALE WIDTH 38MM 110264
68 SPLASHGUARD HTC 800 3MX60MM 110114
69 FOAM 25X2500X20 ETHAFOAM 220E 110241
70 MOTOR PLATE HTC 800 NEW M132 110153
71 FIXING LUG 110072
72 SCREW MC6S M8X25 12,9 310036
73 SCREW M6S M12X45 GALV 310037
74 BRICWASHER BRB M12 GALV 310003
75 NUT NYLOCK M12 GALV DIN985 310004
76 BELT RING HTC 800 NEW 110143
77 BELT, UPPER, HTC 800 NEW MODEL 110126
Parts list - HTC 800 E
