Parts list, HTC 500
The grinding machine’s design may vary based on the year’s model. Machines produced be-
tween 1992 and 1995, for example, have a drive system that is simple to upgrade.
Do not forget to quote the serial number when ordering spare parts. The serial number is located
on the right-hand side of the chassis (seen from behind) and on the right-hand fixing lug. It can
also be found on the nameplate.
Shown below is a parts list corresponding to the exploded diagram on the previous pages.
Pos. Description Part No. Remarks
1 CHASSIS HTC 500 HANDLE 110616
2 CHASSIS HTC 500 POST 110618
3 SCREW M6S M8X25 GALV 310001
4 SCREW M6S M12X85 GALV 310002
5 WASHER BRB M12 GALV 310003
6 WASHER BRB M12 GALV 310003
7 NUT NYLOCK M12 GALV DIN985 310004
8 SPRINT CHASSIS HTC 500 110001
9 SCREW MC6S M8X10 8.8 GALV 310006
10 WATER TANK HTC 500 110002
11 COVER, WATER TANK Discontinued New tank without cover
12 FREQUENCY CONVERTER 11 different models According to specification
12a PROTECTIVE CAGE 110385
13 SCREW M6S M10X35 GALV 310007
14 CHASSIS HTC 500 BOTTOM 110617
15 WASHER TBRB M10 GALV 310008
16 NUT NYLOCK M10 GALV DIN985 310009
17 WATER VALVE TO GRINDER 110007
18 SCREW M6S M5X20 GALV 310010
19 WHEEL FITTING KIT 110008
20 WHEEL HTC 650 WKCP 2803 6553 110350 also 110381, wheel HTC 500
21 MOTOR 4 different models
22 SCREW M6S M12X25 GALV 310011
23 WASHER BRB M12 GALV 310003
24 SCREW MC6S M6X10 8.8 GALV 310005
25 WASHER BRB M6 GALV 310012
26 COVER HTC 500 COMPLETE 110142
27 FIXING LUG 110013
28 WASHER BRB M12 GALV 310003
29 SCREW M6S M10X35 GALV 310007
30 SPLIT PLATE 110014
31 SCREW MF6S M6X20 10.9 GALV 310013
32 BELT RING Discontinued The motor plate and the belt ring
are one piece
33 BELT, UPPER S-140 HTC 500 110016
34 SCREW MFT-TT M6X16 8.8 GALV 310014
