Pos. Description Part No. Remarks
35 MOTOR PLATE HTC 500 110017
36 SCREW M6S M8X25 GALV 310001
37 WASHER TBRSB M8 GALV 310015
38 CIRCLIP SGA 20 310016
39 SHAFT BELT TENSIONER 110018
40 BALL BEARING 6005-2RS C3 110019
41 TENSIONING WHEEL HTC 500 110020
42 BELT, INNER S-250 HTC 500 110021
43 BALL BEARING 6005-2RS C3 110019
44 CIRCLIP SGA 20 310016
45 SCREW MFT-TT M6X16 8.8 GALV 310014
46 UPPER COVER HTC 500 110022
47 FIXING BOSS, NON-ZINC 110023
48 SCREW MFT-TT M6X25 8.8 GALV 310025
49 BEARING CUP, TOP CENTRE HTC 500 110024
50 BALL BEARING 6012-2RS C3 110026
51 BEARING CUP, BOTTOM CENTRE 500 110027
52 CIRCLIP SGA 60 310018
53 CENTRE HUB 110030
54 BALL BEARING 6205 2RS C3 110031
55 BEARING CUP PULLEY UPPER HTC
500
110032
56 FIXING BOSS, NON-ZINC 110023
57 SCREW MFT-TT M6X16 8.8 GALV 310014
58 SCREW MFT-TT M6X16 8.8 GALV 310014
59 SPACER 6205 110033
60 SCREW MC6S M10X60 12,9 310019
61 COVER, CENTRE HUB HTC 500 110034
62 SCREW MFT-TT M6X25 8.8 GALV 310025
63 SCREW M6S M8X25 GALV 310001
64 WASHER TBRSB M8 GALV 310015
65 SHAFT BELT TENSIONER 110018
66 SCREW MFT-TT M6X25 8.8 GALV 310025
67 CIRCLIP SGA 20 Discontinued Gamma ring is used instead
68 GAMMA RING RB 20X35X4 110564
69 SHAFT COVER 110036
70 SPACER 6205 110033
71 BALL BEARING 6205 2RS C3 110031
72 BEARING CUP PULLEY UPPER HTC
500
110032
73 CIRCLIP SGA 25 310021
74 --------
75 --------
76 --------
Parts list, HTC 500
