Parts list HTC 800 (models built before year 2000)
Pos. Description Art.No: Remarks
1 CHASSIS HTC 650/800 HANDLE 110057
2 CONSOLE CONTROL PANEL 110058
3 SCREW RXS B10X16 GALV 310029
4 SCREW MC6S M6X12 8.8 GALV 310030
5 WASHER BRB M6 GALV 310012
6 WIRING HOLDER (CLIP) JR12 110059
7 WASHER BRB M6 GALV 310012
8 SCREW MC6S M6X12 8.8 GALV 310030
9 WIRING HOLDER (CLIP) JR12 110059
10 WASHER BRB M6 GALV 310012
11 SCREW MC6S M6X12 8.8 GALV 310030
12 CHASSIS HTC 650/800 POST 110060
13 SCREW M6S M16X120 GALV 310031
14 WASHER BRB M16 GALV 310032
15 SPRINT CHASSIS HTC 650/800 110061
16 WASHER BRB M16 GALV 310032
17 NUT NYLOCK M16 GALV DIN985 310033
18 SCREW MF6S M8X25 GALV 310071
19 TANK BRACKET 110062
20 WASHER BRB M6 GALV 310012
21 SCREW MC6S M6X12 8.8 GALV 310030
22 FREQUENCY CONVERTER 7.5 kw According to specification
22a PROTECTIVE CAGE 110158
23 SCREW M6S M12X65 GALV 310034
24 NUT NYLOCK M12 GALV DIN985 310004
25 CHASSIS HTC 800 BOTTOM 110619
26 WHEEL FITTING KIT 110008 Only for use with solid
wheels
27 WHEEL HTC 800 110382 More alternatives
available
28 WATER VALVE TO GRINDER 110007
29 SCREW M6S M5X20 GALV 310010
30 WATER TANK HTC 650/800 110069
31 MOTOR 7.5 DPIG 132M-4 200/346 110226
32 SCREW M6S M12X25 GALV 310011
33 WASHER BRB M12 GALV 310003
34 SCREW MC6S M6X25 12.9 GALV 310035
35 WASHER BRB M6 GALV 310012
36 COVER HTC 800 COMPLETE NEW RIGHT 110228 More alternatives
available
37 FIXING LUG 110072
38 MOTOR PLATE HTC 800 110104
39 SCREW MC6S M8X25 12.9 310036
40 WASHER BRB M12 GALV 310003
