HTC 500 - Technical Data HTC 500, HTC 650 and HTC 800

5
Technical data HTC 500, HTC 650 and HTC 800
HTC 500
HTC 650
HTC 800
Model: HTC 502E HTC 504E HTC 504S
Motor output
2.2 kW 4.0 kW 4.0 kW
Current:
10 Amp 16 Amp 16 Amp
Voltage:
220 V 3x380 V 3x380 V
Weight:
120 kg 140 kg 120 kg
Grinder diameter:
500 mm 500 mm 500 mm
Grinding pressure:
100 kg 120 kg 100 kg
Revolutions per
minute:
300-1300 rpm 300-1300 rpm 750 rpm
Water tank
(volume):
17 l 17 l 17 l
Grinding wheels:
3x220 mm 3x220 mm 3x220 mm
Model: HTC 650E HTC 650S
Motor output:
7.5 kW 5.5 kW
Current:
16 Amp 16 Amp
Voltage:
3x380 V 3x380 V
Weight:
240 kg 220 kg
Grinder diameter:
650 mm 650 mm
Grinding pressure:
210 kg 190 kg
Revolutions per
minute:
300-1300 rpm 750 rpm
Water tank
(volume):
40 l 40 l
Grinding wheels:
3x220 mm 3x220 mm
Model: HTC 800HD HTC 800E
Motor output:
11 kW 7.5 kW
Current:
25 Amp 16 Amp
Voltage:
3x380 V 3x380 V
Weight:
315-370 kg 280 kg
Grinder diameter:
800 mm 800 mm
Grinding pressure:
280-335 kg 240 kg
Revolutions per
minute:
300-1300 rpm 300-1300 rpm
Water tank
(volume):
40 l 40 l
Grinding wheels:
3x270 mm 3x270 mm
