HTC 500 - Page 27

27
Pos. Description Part No. Remarks
78 SCREW MFT-TT M6X16 8.8 GALV 310014
79 BEARING CUP MOTOR PLATE HTC 800 110151
80 BALL BEARING 6314-2RS C3 110174
81 UPPER COVER HTC 800 (NEW) 110325
82 SCREW MC6S M8X16 GALV 8.8 310080
83 WASHER TBRSB M10 GALV 310042
84 SCREW MF6S M10X20 310078
85 TENSIONING WHEEL, COMPLETE, HTC 800 110568
86 PULLEY ASSEMBLY, COMPLETE, HTC 800 110567
86A SHAFT JOURNAL 110318
86B VR SEAL 4030-25A 110531
86C RADIAL SEAL CR20X35X7 HMSA 10RG 110291
86D BEARING CUP, UPPER, HTC 800/650 NEW 110296
86E BALL BEARING 6312-2RS1/C3 HT 110289
86F PULLEY HTC 800 NEW MODEL 110295
86G BEARING CUP, LOWER, HTC 800/650 NEW 110297
86H RADIAL SEAL CR 60X75X8 HMSA7 R 110290
86I SCREW MC6S M8X60 12.9 310076
87 COUNTERWEIGHT HTC 650/800 NEW 110315
88 TENSIONING WHEEL, COMPLETE, HTC 800 110568
88A SCREW MF6S M10X20 310078
88B WASHER TBRSB M10 GALV 310042
88C SHAFT BELT TENSIONER 110317
88D BALL BEARING 6207 2RS C3 110078
88E TENSIONING WHEEL HTC 800/650 NEW 110316
88F CIRCLIP SGA 35 310038
89 SCREW MF6S M8X25 GALV 310071
90 BELT, INNER HTC 800 NEW 7.5KW 110288
91 CENTRE HUB 110293
92 BALL BEARING 6207 2RS C3 110078
93 EDGING STRIP HTC 800 NEW 110326
94 FIXING BOSS 110314
95 SCREW MFT-TT M6X16 8.8 GALV 310014
96 BEARING CUP CENTRE HTC 800 110140
97 LOWER COVER HTC 800 NEW 110324
98 SCREW MC6S M8X16 GALV 8.8 310080
99 COVER, INSPECTION HOLE, HTC 800 110141
100 SCREW M6S M5X10 310052
101 SCREW MC6S M12X95 12.9 310051
102 TERMINATION PLUG BRASS M25 M25 110138
103 SCREW MC6S M6X12 8.8 GALV 310030
104 GRINDING HOLDER, COMPLETE, HTC 800 110603
GRINDING HOLDER, COMPLETE, HTC 800EZ 111244
Parts list - HTC 800 E
