HTC 650 HDX - Parts List Chassis

34
Parts list chassis
No. Description Art. No. Qty
1 Water tank HTC 650/800 111355 1
2 Hose large reinforced PVC 111104 1
3 Water valve to grinder 110007 1
4 Chassis HTC 800 HDX 111382 1
5 Handle complete HTC 800 CE 111374 1
6 Power Unit 11 kW CE 111400 1
7 Spacer screw HTC 650 310255 2
8 Screw MC6S M6x16 8.8 zinc-plated 310082 2
9 Screw MC6S M835 8.8 zinc-plated 310189 4
10
Wear protection upper HTC 650 111404 2
11 Screw thermoplastic PT WN 1452
TX
310148
6
12 Washer BRB M6 zinc-plated 310012 2
13
Washer BRB M8 zinc-plated 310077 4
14 Screw MC6S M8x16 zinc-plated 8,8 310080 4
15
Screw MFT M6x16 8.8 zinc-plated 310251 4
16
Wear protection, weight stop 111381 2
17
Drive mechanism, HTC 650 111141 1
18 Washer BRB M24 zinc-plated 310197 4
19 Stop screw P6SS M8x12 45H 310259 2
20
Weight axle 111024 2
21 Wheel HTC 650 111382 2
22 Belongs to wheel HTC 650 111382 2
23
Adjustment bolt Lockable 111037 4
24 Gas spring complete 111385 2
25
Screw MC6S M6x20 310027 4
26
Bow handle 111196 2
27 Weight 32 kg HTC 650 111383
2
No. Description Art. No. Qty
28 Sliding strip, weight 111344 2
29 Screw MFT M6x20 8.8 zinc-plated 310020 4
30 Screw MC6S M8x35 8.8 zinc-plated 310189 4
31
Washer BRB M6 zinc-plated 310012 4
32
Screw thermoplastic PT WN 1452
TX
310148 4
33 Wear protection lower HTC 950 111030 1
34
Shaft chassis/grinding head 111392 2
35 Bushing BM25 111133 2
36 Locking pin LSR 25 310243 2
37 Screw M6S M12x45 zinc-plated 310037 2
38
Nut M6M M12 zinc-plated 310201 2
39 Cover side left HTC 650 111387 1
40
Cover top HTC 650 111388 1
41 Cover side right HTC 650 111386 1
42 Grinding head HTC 650 11kW 111419 1
43
Splash guard HTC 650EZ
2.5mx100mm
110973 1
44 Cover HTC 650 2004 111237 1
45 Pop rivet 4.8x12.7 310084
4
46
Extractor, grinding cover 111012 2
47
Washer BRB M8 zinc-plated 310077 4
48 Screw MC6S M8x20 8.8 zinc-plated 310161 4
49 Velcro male width 38mm 110264 1
50 Suction hose, diam 63 mm 111158 2
