36
No. Description Art. No. Qty
28 Handle ball HTC 950 111038 2
29 Washer BRB M6 310012 2
30 Screw MC6S M6X16 8.8 zinc-plated 310082 2
31
Control casing upper HTC 950 111041 1
Parts list handle
No. Description Art. No. Qty
1 Screw MC6S M6X16 8.8 zinc-plated 310082 4
2 Washer BRB M6 310012 4
3 Packing control panel 111166 1
4 Console instrument panel HTC 800 111289 1
5 Handle HTC 950 111033 1
6 Nut M6M M5 zinc-plated 310193 4
7 Washer BRB 5.3x10x1 310194 4
8 Connecting plate elec. HTC 950 111010 1
9 Screw MC6S M6X16 8.8 zinc-plated 310082 6
10
Control casing lower HTC 950 111043 1
11 Washer BRB M6 310012 2
12 Screw MC6S M6X16 8.8 zinc-plated 310082 2
13
Wall inlet 32A 346-415V 5P RED 110520 1
13
Wall inlet 32A 346-415V 5P BLACK 110613 1
14 Screw MC6S M5x20 zinc-plated 310185 4
15
Handle ball HTC 950 111038 2
16
Pin HTC 950 111028 2
17
Screw MC6S M6X16 8.8 zinc-plated 310082 2
18 Washer BRB M6 310012 2
19 Sprint chassis HTC 950 111023 2
20
Spring HTC 950 110942 1
21 Spacer screw HTC 950 310186 2
22 Attachment pipe handle HTC 950 111027 2
23
Screw MC6S M8x20 8.8 zinc-plated 310161 2
24 Spacer screw HTC 950 310186 2
25
Washer BRB M6 310012 2
26
Pin HTC 950 111028 2
27
Screw MC6S M6X16 8.8 zinc-plated 310082 2
