HTC 650 HDX - Page 42

Parts list grinding head
No. Description Art. No. Qty
1 Screw M6S M12X30 zinc-plated 310128 4
2 Washer BRB M12 zinc-plated 310057 4
3 Motor 11 kW 400/690V 110944 1
4 Lifting eye LH M10 310253 1
5 Screw MF6S M10x30 zinc-plated 10,9 310146 8
6 Bushing 25-40 30-35 111339 2
7 Fixing lug 111377 2
8 Motor plate HTC 650 (-04) 111072 1
9 Belt ring part 1 HTC 650 (-04) 111448 2
10
Belt ring part 2 HTC 650 (-04) 111449 2
11 Screw MFT 6x16 310014 14
12 Screw MC6S M8x20 8.8 zinc-plated 310161 6
13
Hub Motor plate HTC 650 (-04) 111076 1
14 Nilos ring 6017 JV 110950 1
15
Bearing cup 110917 1
16
Ball bearing 6017-2RS1 C3 110951 2
17
Screw MC6S M8x120 zinc-plated 12,9 310235 2
18 Circlip SGA 85 310166 1
19 Belt upper HTC 650 poly-v 111296 1
20
Shaft journal HTC 650-950 110931 2
21 Screw M6S M10x30 zinc-plated 310066 4
22 Screw MC6S M8x20 12.9 310027 8
23
Gamma ring 9RB 25x42x04 110949 2
24 Washer BRB M10 zinc-plated 310048 4
25
Cover center hub HTC 950 110921 1
26
Screw MF6S 8x30 zinc-plated 310182 8
27
Washer BRB M8 zinc-plated 310077 3
28 Screw MC6S M8x20 8.8 zinc-plated 310161 3
29 Screw MFT M5x12 8.8 zinc-plated 310141 6
30 Upper plate HTC 650 (-04) 111070 1
31
Washer BRB M8 zinc-plated 310077 3
No. Description Art. No. Qty
32
Screw M6S M10x30 zinc-plated 310066 2
33 Washer BRB M10 zinc-plated 310048 2
34
Screw M6S M16x30 zinc-plated 310170 1
35 Washer BRB M16 zinc-plated 310032 1
36 Washer BRB M8 zinc-plated 310077 3
37 Screw M6S M10x30 zinc-plated 310066 2
38
Washer BRB M10 zinc-plated 310048 2
39 Washer BRB M8 zinc-plated 310077 3
40
Screw MC6S M8x20 310161 6
41 Screw M6S M10x30 zinc-plated 310066 2
42 Lower Plate HTC 650 (-04) 110068 1
43
Shaft spacer HTC 950 110925 3
44 Axle belt tensioner, lower 110932 2
45
Ball bearing 6207 2rs C3 110078 8
46
Tensioning wheel HTC 950 110933 4
47
Circlip SGA 35 310038 4
48 Belt, inner HTC 650 EX/HDX 111369 1
49 Screw MF6S M6x20 10.9 zinc-plated 310013 16
50 Fixing boss HTC 650-950 110928 16
51
Edging strip HTC 650 (-04) 111069 1
52 Lifting eye LH M10 310253
2
53 Circlip SGH 100 310164 1
54
Shaft Center hub HTC 950 110913 1
55 Ball bearing 6013-2RS1 C3 110946 2
56 Spacer 28 HTC 950 110914 1
57 Circlip SGA 65 310163 1
58
Center hub 111077 1
59 Fitting bolt 16xM12x25 310167 2
60 Tensioning wheel plate, eccentric 110936 2
61
Spacer disk Hub HTC 950 110927 4
62
Shaft belt tensioner, eccentric 110935 2
63 Hub packet 111235 4
