Usage HTC 800 RX
20 2.0
Warning!
There is a risk of crush injuries when the weights are folded back, since these
are not locked in this position.
To obtain a greater grinding pressure, and thereby increased grinding effect, the weights
are lowered forwards, seeFigure4-6, page20.
Figure 4-6. Weights lowered forwards
During normal grinding as well as during transport of the machine, the weights should
be placed in the up position, seeFigure4-7, page20.
Figure 4-7. Weights in the up position
When changing tools and when using tools with a high removal rate (T-Rex™), the
weights should be folded back, seeFigure4-8, page20.
Figure 4-8. Weights folded back
