HTC 800 RX - Handling Weights

HTC 800 RX Usage
2.0 19
The grinder can also be moved short distances using the inbuilt battery drive and with
the support wheel mounted. The battery capacity is sufficient to transport the machine
for ca. 30 minutes.
Figure 4-5. Fitting the support wheel
4.5 Handling weights
The machine is equipped with two weights to make it easy to move the machine's centre
of gravity. Each weight is provided with two locking pins with which the weights can be
lowered and locked in three positions; forward, up (normal position) and backwards.
• Pull each pin out and lock in the extracted position by turning in the direction of
the arrow, seeFigure4-6, page20.
Tip!
We recommend that the weights are folded up during grinding, since if the
grinding pressure is too high and the tool is wrong, it can cause damage to the
machine and the floor.
Warning!
Always make sure that the locking pins lock properly when the weights are
placed in the desired position.
