HTC 800 RX - Machine Operation Modes and Radio Control

HTC 800 RX Usage
2.0 21
4.6 Access to grinding tools
Warning!
The tool becomes very hot during use. Tip the machine back and allow it to
stand for a short while. Use protective gloves when removing the tools.
Warning!
Disconnect the electrical supply when cleaning, changing tools or repairing the
machine.
1. Set the handle to the rear position - see Figure4-2, page17
2. Fold the weights back and place a foot against one of the weights, seeFigure4-9,
page21.
Figure 4-9. Foot on weight
3. Tip the machine backwards carefully, until the weights reach the floor,
seeFigure4-10, page21.
Figure 4-10. Weights on the floor
