17
Remove all sides of the
shipping crate in order to
allow the boiler to be lifted
into its installation location.
Pick the boiler up by the lift
rings to avoid damage to
the boiler enclosure. Use
either a solid ¾” diameter
black iron pipe or lifting
straps to lift the boiler off of
its shipping crate. The
boiler is very heavy. At least
two individuals are needed
to handle the boiler
properly. If the location is
not level, adjust the boiler’s
leveling feet to ensure a
level boiler and proper flow
of condensate. If surface
flooring is rough, care should be taken not to catch the leveling feet and damage the boiler when sliding it
into position.
PART 4 – BOILER PIPING
Never use dielectric unions or galvanized steel fittings when connecting to a stainless steel storage tank
or boiler. Failure to follow this instruction can lead to premature failure of the boiler system. Such failures
ARE NOT covered by warranty.
Plumbing of this product should only be done by a qualified, licensed plumber in accordance with all local
plumbing codes.
A. GENERAL PIPING INFORMATION
The building piping system must meet or exceed the piping requirements in this manual.
The control module uses temperature sensors to provide both high limit protection and modulating
temperature control. The control module also provides low water protection by sensing the water level in
the heat exchanger. Some codes/jurisdictions may require additional external controls.
B. RELIEF VALVE
Connect discharge piping to a safe disposal location following the guidelines on the following page.
