HTRONIC PLS 1000 User Manual

40 | Manual
THE PROFESSIONAL HUMIDITY SWITCH PLS 1000 can measure the
relative humidity and the temperature in two different locations with the help of
two humidity sensors TH-1. The PLS 1000 uses these values to determine the
absolute humidity and the respective dew points. Based on these values and
5 different functions (modes), humidity and temperature switching points can
be set. Fans for incoming air and exhaust air can be controlled directly through
4 integrated potential-free relays. Typical applications are the measurement of
humidity and temperature, automatic ventilation, the drying or humidifying of
rooms, manual control of room fans and the setup of a 2-channel temperature
and humidity switch.
CHARACTERISTICS
– 5 selectable functions (measuring, cellar drying, dT-ventilation, TF-switch,
manual control)
– Remote measurement possible up to 50 meters
– Sensor monitoring for interruption of the sensor line
– Automatic humidity control of bathrooms, sanitary rooms, cellars,
wine cellars, kitchens, etc.
– Direct control of room fans and other consumers via 4 potential-free relays
– Regulation of the room climate
– Dimensions device: 170 x 140 x 68 mm
– Dimensions sensor: 67 x 37 x 22 mm
PROFESSIONAL HUMIDITY
SWITCH PLS1000
Art.- No. 1114630
| 41
Professional humidity switch PLS1000
SPECIFICATIONS
– Operating voltage: 230 V / AC (50 Hz)
– Power consumption (relative idle state): approx. 1 W
–
Switching voltage per relay (AC): max. 230 V / AC max. 12 A
– Switching voltage per relay (DC): max. 24 V / DC max. 10 A
– Max. Switching capacity (total): approx. 2700 VA
– Resolution: 0.1 °C, 0.1% RH, 0.1 g / m³, 1 s
– Settings: 0.1 °C, 0.1% RH, 1 s increments
– Temperature range: -25 ° C to +70 °C
– Accuracy: -25 °C to + 5 °C (max +/- 0,7 ° C)
+5 °C to +60 °C (+/- 0,3 ° C)
+60 °C to +70 °C (max +/- 0.9 ° C)
– Humidity measurement range: 0% RH to 100% RH
– Accuracy: 0% RH to 20% RH (max +/- 4.5% RH)
20% RH to 80% RH (+/- 3% RH)
80% RH to 100% RH (max +/- 4.5% RH)
– Sensors: 2x TH-1 humidity sensor (included)
– Sensor cable: 10 m (extendable up to 50 m)
– Operating temperature: +0 °C to 50 °C
– Protection class: IP20
1. DESIGNATED USE
The professional humidity switch PLS 1000 can measure the current relative humi-
dity and the current temperature in two environments with the help of two humidity
sensors TH-1. The PLS 1000 uses these values to determine the absolute humidity
and the respective dew points. . Based on these values and 5 different functions
(modes), humidity and temperature switching points can be set. Fans for incoming
air and exhaust air can be controlled directly through 4 integrated potential-free
relays. Typical applications are the measurement of humidity and temperature,
automatic ventilation, the drying or humidifying of rooms, manual control of room
fans and the setup of a 2-channel temperature and humidity switch.
