Huawei BTS3900C Installation Guide

27
Installing the BTS3900C Cables
Install the CPRI optical cable (in the BTS3900C configured with the RRU3804).
The procedures for installing the CPRI optical cables in the BTS3900C DC cabinet configured with the RRU3804
and in the BTS3900C AC cabinet configured with the RRU3804 are the same.
 The CPRI optical cable connections in the BTS3900C configured with WBBPd are the same as that of WBBPb.
The following takes the WBBPb as an example.
 WBBPd is supported in V200R012 and later versions.
The CPRI optical
cable is led through
the RRU3804 clip.
Cable hole for the CPRI
optical cable
