Function Description
QoS features Traffic
classification
l Traffic classification based on the combination of
the L2 protocol header, IP quintuple information,
outbound port, and 802.1p priority
l Traffic classification based on the C-VID and C-PRI
of QinQ packets
l Matching internal packet information encapsulated
in a GRE tunnel
l Matching internal packet information encapsulated
in a TRILL tunnel
l Matching internal packet information encapsulated
in an MPLS or VXLAN tunnel
Traffic
behavior
l Access control after traffic classification
l Traffic policing based on traffic classification
l Re-marking based on the results of traffic
classification
l Class-based packet queuing
l Association between traffic classification and traffic
behavior
Priority
mapping
l Mapping from 802.1p priorities to PHBs and colors
l Mapping from PHBs and colors to 802.1p priorities
l Mapping from DSCP to PHBs and colors
l Mapping from PHBs and colors to DSCP
l Mapping from EXP priorities to PHBs and colors
Queue
scheduling
l Priority queuing (PQ) scheduling
l Deficit round robin (DRR) scheduling
l PQ+DRR scheduling
l Weighted round robin (WRR) scheduling
l PQ+WRR scheduling
Congestion
avoidance
l Tail-drop algorithm
l Weighted Random Early Detection (WRED) drop
algorithm
Outbound port
rate limiting
Outbound port rate limiting
ACL-based
simplified
traffic policies
l ACL-based packet filtering
l ACL-based redirection
l ACL-based traffic statistics
