Step 11 Click Log In.
The HMM Web home page is displayed, as shown in Figure 6-9.
Figure 6-9 HMM Web (V603)
----End
6.6 Transferring Files Using WinSCP
Transfer files on the local computer using WinSCP.
Prerequisites
Data
The following data has been obtained:
l IP address of the server to be connected
l User name and password for logging in to the server to be connected
Procedure
Step 1 Enable the SFTP service on the destination device.
Step 2 Open the WinSCP folder, and double-click WinSCP.exe.
The WinSCP Login dialog box is displayed, as shown in Figure 6-10.
NOTE
If the operating system (OS) is not an English system, click Languages to set the displayed language.
CX320 Switch Module
User Guide
6 Common Operations
Issue 09 (2019-08-02) Copyright © Huawei Technologies Co., Ltd. 97
