1.2.1 Front Panel
Figure 1-1 shows the front panel of the HG520b.
LAN4LAN3LAN2LAN1
ADSL
POWER WLAN
INTERNET
Figure 1-1 Front panel of the HG520b
Table 1-1 shows indicators in the front panel.
Table 1-1 Indicators in the front panel
Indicator Status Description
On The HG520b is powered on.
POWER
Off The HG520b is powered off.
On WLAN function is enabled.
Blinking
There are data being transmitted in the
WLAN interface.
WLAN
Off WLAN function is disabled.
On
The connection is established in the LAN
interface.
Blinking
There are data being transmitted in the
LAN interface.
LAN 1–4
Off
No connection is established in the LAN
interface.
