7
Step To... Do...
2
Make sure not
to use the proxy
server.
The process to unselect this function is described
as follows (taking Internet Explorer 6.0 as an
example):
(1) Start the Internet Explorer. Select Tools >
Internet Options... to display the Internet
Options dialog box.
(2) Select the Connections tab. Click LAN
Settings....
(3) Deselect Use a proxy server for your LAN
(These settings will not apply to dial-up
or VPN connections).
3
Log in to the
Web
configuration
page
(1) In the address bar of Internet Explorer, enter
http://192.168.1.1 (the default IP address of
the HG520b). Then press Enter. The login
window is displayed.
(2) Enter the username and the password of the
administrator in the login window.
When the password is authenticated, you
can access the Web configuration page.
î Note:
After configuring the parameters of the HG520b, configure the
computer according to the configuration status of the HG520b. For
details, please refer to
Chapter 3 "Service Configuration."
2.4 Web Configuration Page
The Web configuration page of the HG520b is divided into two parts:
z The navigation tree: It is on the left side of the page. It
provides you to access to different configuration pages.
z Configuration area: It is on the right side of the page.
