System Description
1
Copyright © Huawei Digital Power Technologies Co., Ltd. 2023.
All rights reserved.
System Networking
1.1
Device
PV+ESS
Mains+
ESS
PV+Mains
+ESS
PV+Genset
+ESS
Mains+Ge
nset+ESS
PV+Mains+
Genset+ESS
(A) PV string
√
×
√ √
×
√
(B) DC switch
√
×
√ √
×
√
(D) Power distribution
box (PDB)
√ √ √ √ √ √
(E) Load
√ √ √ √ √ √
(F)
Genset
× × ×
√ √ √
(G) Power grid
×
√ √
×
√ √
(H)
ATS
× × × ×
√ √
(I) Power distribution
cabinet (PDC)
×
√ √ √ √ √
(J) Router
√ √ √ √ √ √
(K) 4G wireless
backhaul module
√ √ √ √ √ √
(L)
FusionSolar Smart
PV Management System
√ √ √ √ √ √
(M)
FusionSolar App √ √ √ √ √ √
(O) Automatic voltage
regulators
× × × ×
√ √
(Q) AC switch
√ √ √ √ √ √
Note: Dashed boxes indicate optional configuration
Single Product System
Note: √ indicates supported and × indicates not supported.
