Huawei NE40E-X2

Board Type Order Name Full Name
CR5D000DE111 16-port E1 flexible card (120 ohms)
CR5D00AUXQ10 4-port 100Base-RJ45 1588v2 flexible card
(supporting AUXQ)
CR5D00C1CF10 1-port channelized OC3c/STM1c POS-SFP
flexible card
B.2 Board Power Consumption and Weight
Table B-3 lists the nominal power consumption and weight of each type of board supported by
the NE40E.
Table B-3 board power consumption and weight
Full Name Powe
r
Cons
umpt
ion
Heat
Dissipation
Weight
Main process Unit MPUG 24 W 78 BTU/hour 0.64 kg ( 1.41 lb )
Network processing Unit NPUI20 200 W 649 BTU/hour 2.62 kg ( 5.78 lb )
8-port 100/1000Base-X-SFP HIC 17 W 55 BTU/hour 0.62 kg ( 1.37 lb )
8-port 100/1000Base-X-SFP 1588v2
HICA
22 W 71 BTU/hour 0.69 kg ( 1.52 lb )
8-port 100Base-X-SFP 1588v2 flexible
card
13 W 42 BTU/hour 0.45 kg ( 0.99 lb )
8-port 100Base-RJ45 1588v2 flexible
card
9 W 29 BTU/hour 0.43 kg ( 0.95 lb )
16-port E1 flexible card (75 ohms) 15 W 49 BTU/hour 0.45 kg ( 0.99 lb )
16-port E1 flexible card (120 ohms) 15 W 49 BTU/hour 0.45 kg ( 0.99 lb )
4-port 100Base-RJ45 1588v2 flexible
card (supporting AUXQ)
10 W 32 BTU/hour 0.44 kg ( 0.97 lb )
1-port channelized OC3c/STM1c POS-
SFP flexible card
17 W 55 BTU/hour 0.55 kg ( 1.21 lb )
HUAWEI NE40E-X1 & NE40E-X2 Universal Service
Router
Hardware Description B List of Boards
Issue 02 (2011-09-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
104
