Pin Cable Remar
ks
Pin Cable Remar
ks
Wire Type Wire Type
19 White Twisted R9 43 White Twisted T9
20 Green 44 Brown
21 White Twisted R10 45 Red Twisted T10
22 Grey 46 Blue
23 Red Twisted R11 47 Red Twisted T11
24 Orange 48 Green
49 Red Twisted R12 73 Red Twisted T12
50 Brown 74 Grey
51 Black Twisted R13 75 Black Twisted T13
52 Blue 76 Orange
53 Black Twisted R14 77 Black Twisted T14
54 Green 78 Brown
55 Black Twisted R15 79 Yellow Twisted T15
56 Grey 80 Blue
Outer
layer
Shielding layer
4.8.3 Technical Specifications
Technical Specifications of the 75-ohm 16xE1 Cable
Table 4-19 lists the technical specifications of the 75-ohm 16xE1 cable.
Table 4-19 Technical specifications of the 75-ohm 16xE1 cable
Item
Description
Cable name Trunk cable - 75ohm-16E1-1.6mm-(Anea 96F-I)-
(SYFVZP75-1.1/0.26*32(S))- +45deg
Connector model Cable Connector,Anea,96PIN,Suite Of Female Connector And
Shielding Case,IDC Type,For 28~30 AWG Solid Wire,1A
Cable model Coaxial Cable - SYFVZP-MC
75-1-1*32-75ohm-12.4mm-1.1mm-0.26mm-Pantone Warm Gray
1U
HUAWEI NE40E-X1 & NE40E-X2 Universal Service
Router
Hardware Description 4 Cables
Issue 02 (2011-09-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
89
