Pin Cable Remar
ks
Pin Cable Remar
ks
Wire Pair
No.
Wire Pair
No.
54 Ring 78 Ring
55 Tip 31 R15 79 Tip 32 T15
56 Ring 80 Ring
Outer
layer
Shielding layer
l 120-ohm 16xE1 cable wiring
Table 4-18 describes the wiring of the 120-ohm 16xE1 cable.
Table 4-18 120-ohm 16×E1 cable wiring
Pin Cable Remar
ks
Pin Cable Remar
ks
Wire Type Wire Type
1 White Twisted R0 25 White Twisted T0
2 Blue 26 Orange
3 White Twisted R1 27 White Twisted T1
4 Green 28 Brown
5 White Twisted R2 29 Red Twisted T2
6 Grey 30 Blue
7 Red Twisted R3 31 Red Twisted T3
8 Orange 32 Green
9 Red Twisted R4 33 Red Twisted T4
10 Brown 34 Grey
11 Black Twisted R5 35 Black Twisted T5
12 Blue 36 Orange
13 Black Twisted R6 37 Black Twisted T6
14 Green 38 Brown
15 Black Twisted R7 39 Yellow Twisted T7
16 Grey 40 Blue
17 White Twisted R8 41 White Twisted T8
18 Blue 42 Orange
HUAWEI NE40E-X1 & NE40E-X2 Universal Service
Router
Hardware Description 4 Cables
Issue 02 (2011-09-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
88
