Table 1-5 Technical specifications of the fan module for the NE40E-X1
Parameter Value
Outline
dimensions
(W x D x H)
50 mm x 226 mm x 130 mm ( 1.97 in. x 8.90 in. x 5.12 in. )
Weight 1.1 kg ( 2.43 lb )
Maximum
power
consumption
100 W
Maximum
wind
pressure
477.2 Pa
Maximum
wind rate
64.4 cubic feet per minute (CFM)
Noise 64.3 dB
Table 1-6 Description of the indicators on the fan module
Indicator/Button
Description
FAN indicator When the indicator is steady green, it indicates that the fan module
works normally.
When the indicator is off, it indicates that the fan module is
unregistered, powered off, or has a hardware fault.
When the indicator is steady red, it indicates that the fan module fails.
1.4 Data Plane
1.4.1 Introduction to the Data Plane
As key parts of the NE40E-X1, Network Processing Units (NPUs) are responsible for data
processing and data switching between Physical Interface Cards (PICs) and NPUIs.
The procedure for data processing is as follows:
1. The IP packets sent from PICs and 2x10G interfaces on an NPU converge at a convergence
module.
2. The Network Processor (NP) processes the IP packets.
3. The Traffic Management (TM) module performs traffic management on the IP packets.
4. The Fabric Interface Chip (FIC) performs IP packet switching.
HUAWEI NE40E-X1 & NE40E-X2 Universal Service
Router
Hardware Description 1 NE40E-X1 Hardware Description
Issue 02 (2011-09-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
11
