Huawei NE40E-X2 User Manual

Table D-5 Specifications of the eSFP-FE-SMTx1310/Rx1550-15km optical module
Parameter Unit Value
Interface standard - IEE802.3ah
Transmission rate Mbit/s 155
Interface type - LC/PC
Transmission distance km 15 ( 9.32 mi. )
Optical transmitter
Optical source type FP Laser
Center wavelength nm TX1310/RX1550
Operating wavelength range nm TX1260-1360
RX1480-1580
Spectral characteristics
Maximum root mean square
(RMS) Spectral Width
nm 7.7
Maximum spectral width
(-20dB)
nm N/A
Minimum side mode
suppression ratio (SMSR)
dB N/A
Average transmit optical power
Maximum transmit optical
power
dBm -8
Minimum transmit optical
power
dBm -15
Minimum extinction ratio dB 8.5
Optical receiver
Operating wavelength range nm 1480-1580
Receiver sensitivity dBm -32
Overload power dBm -8
Maximum optical channel
cost
dB N/A
Maximum reflection factor dB N/A
HUAWEI NE40E-X1 & NE40E-X2 Universal Service
Router
Hardware Description D Optical Module
Issue 02 (2011-09-10) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
119
